GA-60*1series heat resistant silicone rubbers have excellent heat resistance properties, which can make the transparent product. Product contact with food needs to do the two-process treatment at 200℃ 4hours.
GA-60*1F series heat resistant rubber has excellent heat resistance property, suitable for compression molding and extrusion molding. Product contact with food needs to do the two-process treatment at 200℃ 4hours.
Good heat resistance performance among high temperature resistant silicone
Good mechanical property in high temperature resistant rubbers
Heatproof Silicone/ Rubber Application: heat resistance sealings, heat resistance extrusion pipe
| Product code | GA-6041F | GA-6051F | GA-6061F | GA-6071F | |
| Appearance | Faint yellow | ||||
| William plasticity | 150 | 200 | 240 | 240 | |
| Hardness(Shorea) | 40 | 50 | 60 | 70 | |
| Density(g/cm³) | 1.14 | 1.16 | 1.18 | 1.2 | |
| Tensile strength(Mpa) | 8.5 | 9 | 9.5 | 9 | |
| Elongation(%) | 700 | 600 | 500 | 400 | |
| Tear strength(Mpa) | 15 | 20 | 25 | 25 | |
| 300℃*72H hot air aging | Hardness | 46 | 63 | 73 | 77 |
| Tensile strength | 5.2 | 5 | 4.9 | 5.2 | |
| Elongation | 350 | 220 | 180 | 160 | |
Product code | GA-6041A | GA-6051A | GA-6061A | GA-6071A | |
Appearance | Transparent | ||||
William plasticity | 150 | 200 | 240 | 240 | |
Hardness(Shorea) | 40 | 50 | 60 | 70 | |
Density(g/cm³) | 1.14 | 1.16 | 1.18 | 1.20 | |
Tensile strength(Mpa) | 8.5 | 9.0 | 9.5 | 9.0 | |
Elongation(%) | 700 | 600 | 500 | 400 | |
Tear strength(KN/m) | 15 | 20 | 25 | 25 | |
250℃*72h hot air aging | Hardness | 45 | 54 | 64 | 75 |
Tensile strength | 6.2 | 7.3 | 7.5 | 6.5 | |
Elongation | 380 | 300 | 280 | 200 | |
